Frame & Fork
Sizes: 650B Wheel, 19″ Frame
Frame: Claud Butler Alloy Frame
Fork: Zoom suspension fork, 80mm travel, with lock-out and disc mount
Headset: FSA 1.1,8” Cartridge A-headset, Semi-Integrated
Bottom Bracket: Cartridge BB 122mm axle
Steering
Handlebar: Claud Butler 31.8mm Alloy Riser Bar, 0.5″ Rise, 6 degree back sweep, 720mm wide
Stem: Alloy A-head, 31.8mm Clamp, 75mm extension, 10 Degree Rise
Grips: 130mm MTB Grips
Transmission
Shifters: Shimano ST-EF500 3 x 7spd
Front Derailleur: Shimano Tourney FD-TY510 3spd
Rear Derailleur; Shimano Altus RD-TY300 7spd
Freewheel: Shimano Cassette CS-HG200, 7 Speed, 12-32T
Chainwheel: Alloy 170mm cranks, 48x38x28T chainrings
Chain: KMC Z-72
Brakes: Tektro M280 Mechanical Disc Brakes, 160mm rotors
Brake levers: Shimano Alloy Levers
Pedals: 9/16″
Wheels
Front Hub: KT Quick Release alloy disc hub, 36H
Rear Hub: KT Quick Release alloy disc hub, 36H
Rims: 650B Double Wall Alloy, Disc Specific
Spokes: 14G
Tyres: 27.5″ x 2.10″ with tanned sidewall and XC tread
Saddle
Seat Post: Alloy Micro Adjust, 27.2mm x 350mm
Saddle: Claud Butler Custom MTB Saddle
Other
Weight 15kg
Accessories Ping Bell
Frame Size: 19"
