| Frame | TFS II - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max Tyre clearance 700 x 50c |
| Rear Shock | |
| Fork | SunTour NEX HLO; Coil; 63mm travel; Lockout. Max Tyre clearance 700 x 48c |
| Headset | Merida M2346 Neck |
| Stem | Merida Comp TK; aluminium; 31.8mm diameter; adjustable - Length : 80 mm-XXS/XS/S, 90 mm-M/L, 100 mm-XL |
| Handlebar | Merida Comp CC; aluminium; 660mm wide; 25mm rise |
| Grip | Merida Expert EC |
| Brake Type | Hydraulic disc |
| Brake Lever | Shimano BR-MT200 (or Tektro HD-M275 if Shimano supply is delayed) |
| Front Brake | Shimano BR-MT200 (or Tektro HD-M275) hydraulic brake caliper with Shimano RT10; 160mm rotor |
| Rear Brake | Shimano BR-MT200 (or Tektro HD-M275) hydraulic brake caliper with Shimano RT10; 160mm rotor |
| Front Tyre | Maxxis Overdrive Excel; 700 x 40C; wire bead; reflective stripe, Silkshild |
| Rear Tyre | Maxxis Overdrive Excel; 700 x 40C; wire bead; reflective stripe, Silkshild |
| Wheel Size | 700c |
| Rim | Merida Comp TK; 20mm inner rim width; 17mm profile; Material: aluminium |
| Spokes | Black stainless |
| Front Hub | Shimano TX505; 100x9mm; 32 spokes; Centerlock; Quick Release |
| Rear Hub | Shimano TX505; 135x9mm; 32 spokes; Centerlock; Quick release |
| Speeds | 27 |
| Front Derailleur | Shimano M370 |
| Rear Derailleur | Shimano Alivio |
| Shift Levers | Shimano Altus |
| Chain | KMC M99 |
| Cassette | KMC M99 |
| Chainset | SAMOX, AF29-321SSS-P chainwheel with 170mm - XXS/XS/S, 175mm - M/XL length crank |
| Bottom Bracket | FSA TH-7420ST Cartridge Bearing |
| Pedals | VP Components, VPE-891 |
| Saddle | Merida Cross Sport |
| Seat Post | Merida TK; 30.9mm diameter; 10mm lay back; 40mm suspension travel |
