Welcome to Arthur Caygill Cycles

MotorSyncDrive Sport, 70Nm, Powered by Yamaha
ControllerGiant RideControl Ergo
DisplayGiant RideDash Evo
BatteryEnergyPak Smart 625Wh
ChargerEnergyPak 6A smart charger
ColoursCharcoal
FrameALUXX Aluminum, Overdrive 1½ - 1⅛" head tube, integrated KS18 kickstand mount
ForkSR Suntour NEX E25 NLO 75mm travel 15AH
Shock-
HandlebarGiant Connect XC Riser 31.8x 620/690mm
GripsLiv Connect Ergo Microtech Plus, Lock-on
StemGiant Contact
SeatpostGiant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
SaddleLiv Sport Comfort
PedalsAluminum Platform
ShiftersShimano Deore 10 speed trigger
Front DerailleurShimano Deore
Rear DerailleurShimano Deore, 10-Speed, Shadow+
BrakesShimano BR-MT200, hydraulic disc, 180mm
Brake LeversShimano BL-MT200
CassetteShimano CS-M4100, 11-42T, 10-Speed
ChainKMC e.10 Sport, e-bike optimized
CranksetForged Alloy minimal Q-factor, 36/48T
Bottom Bracket-
RimsGiant eX 2, Tubeless Ready, 700c Aluminium
HubsGiant eTracker, [F] 15mm Axle [R] 135mm QR
SpokesStainless steel
TyresGiant Crosscut Gravel 2, 700x45c (622x45), Tubeless Ready, Reflex
ExtrasDirect Mount KSA18 Trekking Kickstand
LightingAxa BlueLine 50Lux Steady E6 frontAxa BlueLine Steady E6 rear
Lock-
CarrierMIK rack. System bag & basket compatible
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
Sizes: XS, Small
